Designed to be both cost-effective and practical, it is crucial for manufacturers looking to enhance their capacity in quality processes or purchase their first coordinate measuring machine (CMM) to find a balance between performance and price.

Entry-level CMMs fulfill all essential inspection requirements, offering consistent precision and reliability in a single device.

1) GLOBAL Lite

GLOBAL-Lite

GLOBAL Lite is a specialized entry-level coordinate measuring machine (CMM) system designed for manufacturers on a budget who need to measure basic quality. This affordable and flexible solution serves as an excellent starting point for automated dimensional inspection. For small and medium-sized businesses looking to meet increasing consumer demand, investing in metrology equipment is often essential.

GLOBAL Lite represents the ideal entry point for expanding automated metrology capabilities. This CMM offers the best price-to-performance ratio to satisfy initial budget constraints and production throughput needs. Quality specialists with limited experience using automated CMMs will find GLOBAL Lite’s user interface and straightforward configuration particularly user-friendly. As your business grows, GLOBAL Lite is ready to adapt to your expanding inspection needs.

Features & Benefits

Outstanding Cost-Capability Ratio

With the right combination of speed and precision for constrained budgets, GLOBAL Lite is an ideal choice for manufacturers looking to enhance their competitiveness through automated measurement.

Adaptable to Business Expansion

Hexagon’s end-to-end solutions can be integrated with GLOBAL Lite to accommodate your evolving business needs and application requirements.

Maximum Usability

Even professionals with limited experience in Coordinate Measuring Machines (CMMs) can start measuring immediately and improve their inspection skills, thanks to the user-friendly design of GLOBAL Lite.

Optimized Construction

GLOBAL Lite features a robust construction that ensures reliable performance while optimizing production space. Its ultra-rigid frame, excellent stiff-to-mass ratio, and compact dimensions make it a perfect fit for various environments.



2)GLORY

The GLORY coordinate measuring machine (CMM) is a new type of universal measuring device. Developed by Hexagon, it incorporates advanced core technologies and nearly three decades of experience in industrial metrology, offering a highly flexible measurement platform. There are two models of the GLORY CMM: Touch and Scan. Each is designed to handle a wide range of measurement tasks within their specific application categories.

By integrating various tactile and non-contact sensors along with different indexing probe heads, users can choose the best solution for their needs. The CMM allows for quick switching between measurement techniques to accommodate different parts and features. Furthermore, the GLORY CMMs utilize the industry-leading metrology software PC-DMIS, which enhances workflows for all types of measurement processes.

GLORY

Features

Active Damping of Vibrations

In automated measuring cells or near production lines, an active vibration damping system enhances the resilience of Coordinate Measuring Machines (CMMs) to ground vibrations.

Modular Rack Systems for Probes and Sensors

GLORY provides flexible and modular rack systems that facilitate continuous measurements and automatic modifications during measurement procedures.

Fly2 Mode: Streamlined Measurements

Fly2, a new generation of flight control technology, optimizes the measurement path, significantly reducing hold-up and idle time during the measurement process. This innovation increases measurement efficiency by over 10%, thereby enhancing production.

Scan Pilot: Navigating Uncharted Territories with Your CMM

Scan Pilot is an innovative scanning navigation technology that greatly improves accuracy when scanning unknown areas.

Energy is conserved through the use of ECO Mode and ECO Mode+.

When the CMM (Coordinate Measuring Machine) is not in operation, ECO Mode enables it to shut off automatically. ECO Mode+ significantly enhances energy efficiency by automatically shutting down the system and cutting off the compressed air supply to the air bearings after a predetermined period of inactivity. Once in ECO Mode or ECO Mode+, the CMM will restart and perform its tasks without any human intervention.

Integration of Automation

GLORY offers easy integration into automation systems, transitioning from manual to semi-automatic and then to fully automated processes, as well as from offline to near-line and near-line to inline configurations. The system is modular and plug-and-play, meeting automation requirements at every level.



Measuring volume

Type X (Width) Y (Depth) Z (Height)
 04.05.04  400 mm  500 mm  400 mm
 05.06.05  500 mm  600 mm  500 mm
 06.08.06  600 mm  800 mm  600 mm
 06.10.06  600 mm  1000 mm  600 mm
 08.10.06  800 mm  1000 mm  600 mm
 08.15.06  800 mm  1500 mm  600 mm
 10.12.08  1000 mm  1200 mm  800 mm
 10.15.08  1000 mm  1500 mm  800 mm
 10.21.08  1000 mm  2100 mm  800 mm
 12.15.10  1200 mm  1500 mm  1000 mm
 12.22.10  1200 mm  2200 mm  1000 mm
 12.30.10  1200 mm  3000 mm  1000 mm
 15.22.10  1500 mm  2200 mm  1000 mm
 15.30.10  1500 mm  3000 mm  1000 mm
 15.22.12  1500 mm  2200 mm  1200 mm
 15.30.12  1500 mm  3000 mm  1200 mm
